Sealey Rapid Bench Pillar Drill 5-Speed 240v 820mm

Sealey Rapid Bench Pillar Drill 5-Speed 240v 820mm

Heavy-duty construction. Safety devices fitted include a no-volt release switch and pulley cover cut-out microswitch. Radial feature allows off-table drilling and angle drilling. Features a maximum throat depth of 420mm. Radial arm controlled by rack and pinion assembly allowing fine positioning of drill bit. Also available as floor standing type – GDM1630FR.

Features:
– Heavy-duty construction.
– Safety devices fitted include a no-volt release switch and pulley cover cut-out microswitch.
– Radial feature allows off-table drilling and angle drilling.
– Features a maximum throat depth of 420mm.
– Radial arm controlled by rack and pinion assembly allowing fine positioning of drill bit.
– Also available as floor standing type – GDM1630FR.

Specifications:
– Model No: GDM790BR
– Base Size: 345 x 215mm
– Collar Diameter: 60mm
– Column Diameter: 60mm
– Drilling Capacity (Chuck Size): 16mm
– Maximum Distance Spindle to Base: 470mm
– Maximum Distance Spindle to Table: 300mm
– Motor Power (Start): 350W(550W)
– Nett Weight: 43kg
– Number of Speeds: 5
– Optional Accessories: GDMX/KC – Keyless Pillar Drill Chuck 16mm
– Overall Height: 820mm
– Radial Arm Travel: 285mm
– Speed Range: 500-2450rpm
– Spindle Centre to Column: 420mm
– Spindle Nose Taper: MT2
– Spindle Travel: 80mm
– Supply: 240v
– Swing: 840mm
– Working Base Surface Size: 160 x 180m

1 Year Manufacturers Warranty
